Distortion in Forged Rolled Rings

The thermal and rolling treatment of forged rolled rings sometimes leads to the creation of residual stresses, causing dimensional distortion in the results. However, there are tons of corrective measures employed by forging industries to address this concern. Ongoing studies are seeking to base newly-found corrective measures on the laws of physics.

How does Dimensional Distortion Happen?

Ring Rolling Process

First, the rings and other metal components are rounded and cut to how much it weighs. It is then processed to reach the intended integrity, directional grain, and other specifications. It is then punched and pierced to create a ring.

After that, it is placed on the ring mill to be rolled. The idler roll applies pressure against the drive roll and slowly the ring diameters are increased. Continued pressure is applied, and this reduces the wall thickness.

The axial rolls control the height as it is being rolled and this is repeated until the proper size and specifications are reached.

Distortion is Not the Only Problem

Once the metal components have been rolled at a certain forging temperature, most of them are heat treated. Due to this method, some parts of the components become ovular and distorted.

This occurs more often in huge metals with outer-diameter to wall-thickness proportions. More so, distortion is the only concern resulting from this method. Despite furnishing results that meet dimensional tolerances, residual stresses may still happen even after the product has been shipped to the customer.

The reason is that succeeding machining processes conducted by customers or other metal-production companies may cause extra distortion and deformation to the product.

Preventive Measures Must be Employed

In light of the intricacy of the issue, various ring-rolling companies approach it with only corrective measures while disregarding the essential preventive measures. There are companies which manufacture the metal components with great tolerances so it can be earlier manufactured to its final dimension and preventing any possible distortion.

Others employ corrective ring distortion measures through expansion and compression processing, partially relieving the components of residual stresses.

Where can I find forged rolled rings?

Looking for Forged Rolled Rings with Minimal Distortion?

To produce rings and other metal parts with minimal distortion, it’s important that the ring-rolling company employ both corrective and preventive measures, if possible. Contact Ferralloy Inc. to get your quality rolled rings!

Advantages of Carbon Rolled Rings

Are you interested in utilizing the advantages of carbon rolled rings for your next project? If yes, contact Ferralloy, Inc., because our team can supply you with rolled ring forgings in diameters up to 110” and in various materials ranging from carbon to stainless steel.

where can i find rolled rings?

What Benefits Can Carbon Rolled Rings Offer?

Economical

When using carbon in the rolled ring process, the forged components made from this material tend to be cheaper than other rolled ring materials. Additionally, there are excellent forging tools to enhance the manufacturing process’s efficiency. Aside from being economical, it may considerably reduce the waste produced during the process.

Production of Various Shapes

To produce various shapes of forged components, it is required that the forging process also involves different methods. Since carbon steel forgings are incredibly flexible, it is easier to create them in different shapes. The most common shapes produced by this rolled ring process are hubs, discs, blocks, seamless rolled rings, and flanges.

Challenging Applications

Forged materials are enforced to play a critical role in various challenging applications such as pressure vessels, power generators, aircraft components, and oil rigs. The capacity of carbon rolled ring products to tolerate resistance makes them an excellent option for such applications. Additionally, the forged components produced are available in different sizes and grades.

Metal Grades

Aside from different sizes and shapes, carbon rolled rings have four distinct grades. These metal grades significantly differ from one another on the basis of their hardness, endurance, wear, and strength. This allows companies, using forged components, to choose a category that ideally suits their standards. While there are several alloys that can provide industries with various metal grades, no other alloy can provide the versatility of carbon rolled rings.

where can i find rolled rings?

Where to Find Carbon Rolled Rings?

If you’re one of those industries that want to purchase and secure quality carbon rolled rings, you can contact Ferralloy Inc. today!

Titanium Seamless Rolled Ring Forging

A process used widely and performed to the highest level by Ferralloy is seamless rolled ring forging. It plays an important role in the manufacturing of certain components. Forging is a method of manufacturing inherently stronger components for machinery.

When apparatuses are needed to develop wind turbines or high-quality gears are required for mechanical parts, the ring forging process is used to manufacture superior pieces. The forging process uses different metal and alloy types to comply with the highest standards – among the most commonly used is titanium.

what are seamless rolled ring forging?

Why is Titanium Used in Seamless Rolled Ring Forging?

Applications

Titanium can be used for a wide range of metal parts, from tubing to bolts to fasteners. And this metal alloy is used for good reasons. The list of titanium benefits is a long one. Titanium seamless rolled ring forging is applied in water treatment, desalination, power generation, marine, chemical processing, aerospace military, and medical technologies.

Features

Aside from the fact that titanium rolled ring forging has many applications, its features are exceptional. It provides efficient low thermal expansion, low elasticity module, non-toxic and non-magnetic, high melting point, exceptional oxidation capabilities, and exceptional bearing to cryogenics property. Other notable features are:

  • Excellent corrosion resistance
  • Outstanding strength-to-weight percentage
  • Low density
  • High-heat resistance

Main Properties

What makes titanium a special forging material is its properties. According to forging experts, the following are titanium’s main properties that make it an exceptional material for forging processes.

  • Hydrogen storage
  • Superconductivity
  • Shape memory
  • Low damping resistance, modulus of elasticity, thermal conductivity, non-magnetic, and density
  • High-temperature easy oxidation, strength, and heat resistance

Likewise, titanium rolled ring forging offers tensile strength close to yielding strength, good performance at low temperatures, and exceptional corrosion resistance.

what are seamless rolled ring forging?

Where to Look for Titanium Seamless Rolled Ring Forging

Are you interested in using these metal components for your next project? At Ferralloy Inc., we are a quality-driven organization that is committed to constant improvement and customer satisfaction.

Why Forging Rings is a Priceless Asset

Are you into forging? If yes, you probably have researched how to forge the best rings. If you haven’t and want to be an excellent blacksmith, you need to learn how forging rings work. Since forging rings is one of the essential techniques in blacksmithing, it’ll become your priceless asset in the future. Below are the reasons why forging rings is considered to be a priceless asset.

What are forging rings?

Perks over Learning How to Forge Rings

Cost-Effective and Flexible Production

Other metalwork procedures like special performance castings need longer lead times, complicated process controls, and pricey materials. With forging processes like ring rolling and open-die processes, you can easily adapt to different production run lengths and set up less lead time.

Better Heat Treatment Response

Another remarkable factor about forging rings is that it offers a great heat treatment response. Other methods like castings need close control cooling and melting processes to prevent alloy segregation. If this is not prevented, it will lead to a non-uniform heat treatment response that will compromise finished products’ straightness. When it comes to forging rings, the intricate process responds better to heat treatment, resulting in exceptional dimensional stability.

Use of Various Materials

Ring forging can be very useful since it can be used in several forgeable components such as aerospace metals, carbon, stainless steel, or alloy. Its versatility allows the rings to be more responsive and flexible. This is precisely why the industries engaged in refinery, chemical, and power generation choose this process.

Strength

The strength factor of this process is the most notable advantage why blacksmiths often choose the metalwork process. Experts say that forgings have more strength than other components. It can maintain the power of the metal despite temperature fluctuations.

What are forging rings?

Learn More About Forging Rings

At Ferralloy Inc., we only provide excellent quality metalwork and always aim to offer better business cooperation with every customer. If you want to know more about forging rings and where to get products made according to this forging process, schedule an appointment with us today!

Quality Materials Used in Seamless Rings

Seamless rings are produced through a process called ring rolling. It uses a machine called a rolling mill and is intricately forged to produce near net shapes. When it comes to the making of the seamless rolled ring, various materials are used. Let’s take a look at some of the different materials used to make seamless rolled rings.

What are seamless rings?

Materials Used and Product of Seamless Rolled Rings

The Materials

The difference and outcome in seamless rolled ring forging depend on the material used. The hardness, strength, and ability to resist wear are all critical factors. However, the most critical factor is to resist wear since most of the products are used in engines and machines. Additionally, seamless rolled ring products must be able to sustain high temperatures.

To create quality products, manufacturers use aluminum, stainless steel, or alloy steel. Since most of the products are used in heavy-duty work, the strength of the material must withstand great impact.

Aluminum is incredibly popular in the aerospace, defense, and transportation industries. In contrast, stainless steel is used in various industrial applications where moderate strength and enhanced corrosion resistance are required. Lastly, alloy steel is used to increase the strength of the metal.

The Products

Most of the products made from seamless rolled ring forgings are used in bushings, oilrigs, equipment for mining, and other farm or industrial machinery. Several factories also use specialized equipment so they can cope with the high levels of heat.

The most common industry that uses seamless rolled ring forgings in the aerospace industry. This process is used to give extra strength to certain components that combat pressure. It is commonly used in wheel bearings and other parts of the aircraft.

What are seamless rings?

Where to Get Quality Seamless Rings

It doesn’t matter what your desired material is. You can count on Ferralloy, Inc. to deliver top quality seamless rolled rings. Our team is highly trained to scout and determine only quality products to satisfy your needs. If you want to inquire more about our products, contact us through this link.

Plate Burnout versus Rolled Ring Forging

Rolled ring forgings are needed for several types of applications. The use of metal components may vary in size, thickness, and diameter. If you want to achieve a strong, durable, and cost-effective metal ring for your project, there are forging processes you need to be aware of. These processes include rolled ring forgings and plate burnout. Keep reading to learn the differences between the two to manufacture a metal ring.what are rolled ring forgings?

Difference between Plate Burnout and Rolled Ring Forging

Rolled Ring Forging

In the manufacturing process of seamless rolled ring forging, the waste of the metal that is punched out is prevented, and the metal piece is forged to become stronger and more durable. A donut shape is formed from metal and then forged into the metal ring that is desired.

The size and diameter are shaped from this donut-shaped metal as it reaches extremely high temperatures to the point that it becomes malleable. This process saves metal waste due to the process when the ring is punched out, making it a more cost-effective process. Aside from being cost-effective, rolled ring forging can provide strong and durable metal components.

Plate Burnout

As for the plate burnout process, it involves many processes in which a metal ring can be achieved. Just like rolled ring forgings, the process begins with a plate of metal. Once the component specifications are determined, the plate is punctured in the metal ring’s shape and size. This type of method makes the metal ring more susceptible to fatigue because the plates are exposed to extreme heat and pressure.

what are rolled ring forgings?

Determine Whether Plate Burnout or Rolled Ring Forging is the Best Process for your Project

For all of your metal manufacturing needs, Ferralloy Inc. has the authority and experience to help you. Our industry leaders in metalworking can suggest the best methods for manufacturing your metal parts and components at competitive rates. We are dedicated to producing and delivering the highest quality products to fulfill your project in the best manner. Contact Ferralloy Inc. today to inquire about your metalworking needs!

Development and Characterization of Ring Rolling

Have you ever wondered how the ball and roller bearing races, pressure valves, pipes, and turbines are made? These metal pieces are produced through a process known as ring rolling. This is a specific category of metal rolling wherein a smaller diameter ring is rolled into a reduced cross-section and an accurate ring of larger diameter. Below are the facts about what ring rolling is, as well as its developments and characterization.

What is ring rolling?

Facts to Know About

What is it?

Ring rolling is accomplished by using two rollers, one idle and one driven. The rollers move on either side of the ring’s cross-segment to create an efficient and precise motion. To guarantee the ring will maintain an unbroken width pattern the entire forming process, manufacturers use an edging roller during the industrial metal rolling process.

What are the Characteristics?

The process will retain the same volume of the metalwork. In this way, the geometric reduction in thickness will be reimbursed entirely because of the upturn in the ring’s diameter. Among the many characteristics, the most notable one is the manufacturing of seamless rolled rings. This procedure is used to produce not only flat rings but also rings that are designed to have different shapes and cross-sections.

Another significant characteristic of this process is that it can produce accurate parts and components with little waste of material. Additionally, the process involves an enhanced grain orientation that provides the metal robust strength appropriate for several applications.

What are the Developments?

This technique is gearing towards the new metalwork process with heightened geometries and more complex cross-section geometries. The applied knowledge gathered through the years by experts is insufficient to estimate the precise interface of various process parameters. Nonetheless, experts and manufacturers can still rely on simulation software to produce an accurate ring rolling model and evaluate the material properties and material flow with accuracy.

What is ring rolling?

Complex Facts About Ring Rolling

When it comes to forging, it is ideal that you get advice from specialists. We know this matter involves intricate and elaborate details. At Ferralloy Inc., we make sure that you are provided with detailed information about the engineered products we offer.

Reasons to Try Seamless Rolled Rings

Many industries use seamless rolled rings. Moreover, it may even surprise you to know that many industries like aviation and food processing use these rings in their regular line of work! So, why do so many companies from opposite paths of industry opt for seamless rolled rings? Let’s find out.

What are seamless rolled rings?

The Exceptional Process and Materials

Process Involved

The forging process starts with a circular metal component. Next, the component is cautiously pierced to create a hollow ring that looks like a doughnut. Then, the ring is moved and processed to recrystallization temperatures. Finally, after the recrystallization process, it is placed onto the idler roll and under pressure, directed towards the drive roll to produce the desired product.

Types of Rolled Rings

There are three main types of rolled rings:

  • Carbon – commonly used for pressure and structural vessel applications
  • Alloy – used for gear and bearing applications in addition to a variety of industrial equipment applications
  • Stainless Steel – mostly used for food and chemical processing applications.

Materials or Components Used

Seamless rolled rings can be made from any forgeable material! Furthermore, these include, but are not limited to:

The ability to create seamless rolled rings out of a wide range of materials is one of the many reasons why so many companies choose to work with them.

What are seamless rolled rings?

Advantages of Using Seamless Rolled Rings

Seamless rolled rings are used by various industries for many reasons. Moreso, some of the common reasons are a broader range of materials, better performance under heat, reduced costs, and greater strength. These rings can be created from numerous forgeable materials, including aerospace metals, carbon, stainless steel, and alloy.

Additionally, unlike the other ring components, it is easier to predict how these rings will react. These rings can maintain their strength despite the fluctuating temperature. To know more about seamless rolled rings, contact Ferralloy Inc. today!

Understanding Alloy Rolled Rings

Alloy rolled rings contain quality alloy elements to create products with high treat response and improved physical and mechanical properties. It likewise produces metal works with fatigue resistance and enhanced strength.

These products or metal works are commonly used for bearing and gear applications alongside numerous industrial equipment applications.

where to find quality rolled rings

All About Alloy Rolled Rings

Why Choose Alloy for Rolled Rings

According to metalwork experts, alloy rolled rings do not require any inventory because there is no need to stock plate in several thicknesses. Likewise, experts say that it produces little or no waste at all since there are no expensive plates involved.

Another reason why you should choose alloy rolled rings is that it’s cost-effective. When compared to carbon and stainless steel rolled rings, the use of alloy steel eliminates production time, layout time, and complicated cost handling. More so, this type of rolled ring provides exceptional structural integrity by forging the products in a radial pattern.

Types

The common types of alloy rolled rings are waspaloy, Inconel, and hastelloy X. Waspaloy is a nickel-based superalloy with an age-hardening feature that gives this seamless rolled ring forging useful strength. This type of exotic alloy works best on provisions with solution-annealed conditions.

Another type of exotic alloy is Inconel. It is a family of non-magnetic stainless steels and can sustain their structural integrity despite being exposed to excessive temperatures. Additionally, they are resistant to oxidation and are typically used in applications that need materials that yield corrosion caused by stress-corrosion cracking and high purity water.

Lastly, Hastelloy X is an alloy composed of molybdenum, iron, chromium, or nickel, making it both resistant to extreme temperatures and oxidation. It provides good ductility and is definitely easy to fabricate.

quality alloy rolled wings

Capabilities of Alloy Rolled Rings

At Ferralloy Inc., our team works hard to produce products or metal works produced through exceptional grain flow. Our all-inclusive internal structure provides greater mechanical properties. Alloy rolled rings undergo precision rolling processes to create surface smoothness and first-rate concentricity.

Additionally, Ferralloy Inc. is a solutions provider that offers high-quality alloy steel rolled rings throughout the country. Contact our team today to request a quote.

Understanding Carbon Steel Rolled Rings

Creating carbon steel rolled rings is a process that uses carbon steel. It contains up to around 1.2% carbon while other present elements are in quantities too small to impact its properties. With this material, carbon rolled rings are commonly used for pressure and structural vessel applications. To understand more about carbon steel rolled rings, below are the facts you need to know.

seamless-rolled-rings

All About Carbon Steel Rolled Rings

Why Choose Carbon Steel

Manufacturers engaged in rolled ring production will tell you that carbon steel is among the most cost-effective option when it comes to steel. Since it is cost-effective, the rolled rings process can attain the high strength a stainless steel can offer. However, you can still achieve good quality products that can be hardened through tampering and quenching.

Carbon Steel Grades

High-grade carbon steel rolled rings is often used in applications that don’t require high temperature or high strength environments. Below are the carbon steel grades you need to familiarize yourself with.

  • A Grade – This type of carbon steel is ideal for oil field applications since it is corrosion resistant. It comprises alloy substance such as nickel or manganese. Thus, it can enhance the toughness and hardenability of the metal produced.
  • High Carbon Steel – Akin to A Grade carbon steel, this type also comprises manganese to improve hardenability and toughness. It can be heat treated or welded for higher durability.
  • Low Carbon Steel – This is commonly known as re-sulfurized carbon steel as it contains sulfur to provide exceptional machinability.
  • Plain Carbon Steel – The least expensive type but provide a good welding factor. It comprises high carbon content and low alloy content. Hence, plain carbon steel can offer excellent surface hardness and good toughness.

Capabilities of Carbon Rolled Ring

Carbon rolled rings utilize a foolproof forging process that creates seamless rolled rings with outstanding circumferential grain flow and ample internal structure. Also, the precision rolling procedure offers exceptional surface smoothness and concentricity.

forged-rolled-rings

Want High-Quality Carbon Rolled Rings?

Ferralloy Inc. is a solutions provider that offers high-quality carbon steel rolled rings. Products are delivered according to the preference and most demanding requirements of clients. Contact us today!
